2. Quickstart

In this quickstart, we'll show how to use compile_dataset to create a DecompiledCodeDataset from a sample C repository.

Prerequisites

Before getting started, make sure you have the following installed:

  • Python 3.8+
  • gcc (for compiling C binaries)
  • make (to build the example repository)
  • Ghidra (to decompile the built binaries)

Step 1: Download and decompress the example repository

Download the provided example C repository, then decompress it.

Step 2: Create the dataset

Use compile_dataset to build the repository, extract functions from the source code and binaries, and organize them into a structured dataset:

import codablellm

dataset = codablellm.compile_dataset(
    'path/to/demo-c-repo',              # Path to the repository
    [
        'path/to/demo-c-repo/main_app',
        'path/to/demo-c-repo/tool',
    ],                                  # Binaries that will be built and decompiled
    'make',                             # Command/script path used to build the repository
)

When compile_dataset is called, codablellm first executes the build command (make in this case) to build the binaries of the repository (path/to/demo-c-repo/main_app and path/to/demo-c-repo/tool). Then, it extracts functions from both the source code and the built binaries (using Ghidra to decompile the binaries). These functions are compared and mapped, creating a DecompiledCodeDataset. This dataset allows you to see decompiled functions alongside their potential corresponding source code functions, offering a bridge between low-level and high-level representations.

Step 3: Export the dataset to a CSV

Finally, export your dataset into a CSV file. For more export formats, see Dataset.save_as:

dataset.save_as('./demo-c-repo-dataset.csv')

Visual Overview

visual overview

Final note

This quickstart provides a minimal working example of how codablellm can create datasets from a simple C project. In the following sections, we'll dive deeper into:

  • How to generate source code datasets
  • How to generate decompiled code datasets from already compiled binaries
  • How to manage and customize source code function extraction
  • How to control and customize build processes
  • How to configure and manage decompilers
